Dipti Metal Industries is the Largest Spring Washers DIN 127B Manufacturer, Spring Washers DIN 127B Supplier, and Exporter of high-quality Spring Washers DIN 127B (Form B) in India. We are a Leading Spring Washers DIN 127B Stockiest and Spring Washers DIN 127B Distributor of Split Lock Washers with Flat Ends in Mumbai. Our Spring Washers are manufactured to precise German standards (DIN) and are available Spring Washers DIN 127B in Stainless Steel (304, 316), Spring Washers DIN 127B Carbon Steel, and Exotic Alloys. As a Top Spring Washers DIN 127B Dealer and Biggest Spring Washers DIN 127B Supplier in Mumbai, we offer wholesale prices on Spring Washers M2 to M68 sizes, ensuring vibration-proof joints for global industries.
Standard Metric Dimensions for Spring Washers DIN 127 Form B (Flat Ends) - Spring Washers DIN 127B Manufacturer in India.
| Nominal Size (Bolt Size) | Inner Diameter (d1) min (mm) | Outer Diameter (d2) max (mm) | Thickness (s) (mm) | Width (b) (mm) |
|---|---|---|---|---|
| Spring Washer M2 | 2.1 | 4.4 | 0.5 | 0.9 |
| Spring Washer M2.5 | 2.6 | 5.1 | 0.6 | 1.0 |
| Spring Washer M3 | 3.1 | 6.2 | 0.8 | 1.3 |
| Spring Washer M3.5 | 3.6 | 6.7 | 0.8 | 1.3 |
| Spring Washer M4 | 4.1 | 7.6 | 0.9 | 1.5 |
| Spring Washer M5 | 5.1 | 9.2 | 1.2 | 1.8 |
| Spring Washer M6 | 6.1 | 11.8 | 1.6 | 2.5 |
| Spring Washer M8 | 8.1 | 14.8 | 2.0 | 3.0 |
| Spring Washer M10 | 10.2 | 18.1 | 2.2 | 3.5 |
| Spring Washer M12 | 12.2 | 21.1 | 2.5 | 4.0 |
| Spring Washer M14 | 14.2 | 24.1 | 3.0 | 4.5 |
| Spring Washer M16 | 16.2 | 27.4 | 3.5 | 5.0 |
| Spring Washer M18 | 18.2 | 29.4 | 3.5 | 5.0 |
| Spring Washer M20 | 20.2 | 33.6 | 4.0 | 6.0 |
| Spring Washer M22 | 22.5 | 35.9 | 4.0 | 6.0 |
| Spring Washer M24 | 24.5 | 40.0 | 5.0 | 7.0 |
| Spring Washer M27 | 27.5 | 43.0 | 5.0 | 7.0 |
| Spring Washer M30 | 30.5 | 48.2 | 6.0 | 8.0 |
| Spring Washer M33 | 33.5 | 55.2 | 6.0 | 10.0 |
| Spring Washer M36 | 36.5 | 58.2 | 6.0 | 10.0 |
| Spring Washer M39 | 39.5 | 61.2 | 6.0 | 10.0 |
| Spring Washer M42 | 42.5 | 68.2 | 7.0 | 12.0 |
| Spring Washer M45 | 45.5 | 71.2 | 7.0 | 12.0 |
| Spring Washer M48 | 49.0 | 75.0 | 7.0 | 12.0 |
* Note: We are a Spring Washers Manufacturer capable of producing custom sizes up to M100 upon request.
Weight in kgs. per 1,000 pcs. unless otherwise specified. All weights are approximations. Provided by Dipti Metal Industries, the Leading Stockiest.
| Size (Nominal) | Weight (kgs / 1000 pcs) |
|---|---|
| Spring Washer M2 | 0.033 |
| Spring Washer M2.2 | 0.050 |
| Spring Washer M2.5 | 0.053 |
| Spring Washer M3 | 0.11 |
| Spring Washer M3.5 | 0.12 |
| Spring Washer M4 | 0.18 |
| Spring Washer M5 | 0.36 |
| Spring Washer M6 | 0.83 |
| Spring Washer M7 | 0.93 |
| Spring Washer M8 | 1.60 |
| Spring Washer M10 | 2.53 |
| Spring Washer M12 | 3.82 |
| Spring Washer M14 | 6.01 |
| Spring Washer M16 | 8.91 |
| Spring Washer M18 | 9.73 |
| Spring Washer M20 | 15.2 |
| Spring Washer M22 | 16.5 |
| Spring Washer M24 | 26.2 |
| Spring Washer M27 | 28.7 |
| Spring Washer M30 | 44.3 |
| Spring Washer M36 | 67.3 |
| Spring Washer M39 | 71.7 |
| Spring Washer M42 | 111 |
| Spring Washer M45 | 117 |
| Spring Washer M48 | 123 |
| Spring Washer M52 | 182 |
| Spring Washer M56 | 193 |
| Spring Washer M60 | 203 |
| Spring Washer M64 | 218 |
| Spring Washer M68 | 228 |
Dipti Metal Industries, the Largest Spring Washers DIN 127B Exporter and Manufacturer in India, supplies washers compatible with international standards. Cross-reference chart below:
| Region / Country | Standard Body | Equivalent Standard | Description |
|---|---|---|---|
| Germany / Europe | DIN | DIN 127 B | Spring lock washers with square ends (flat). |
| India | IS | IS 3063 | Single Coil Rectangular Section Spring Washers. |
| USA / ANSI | ASME/ANSI | ASME B18.21.1 | Helical Spring Lock Washers. |
| United Kingdom | BS | BS 4464 | Spring washers for general engineering (Metric). |
| Japan | JIS | JIS B 1251 | Spring lock washers. |
| Russia | GOST | GOST 6402 | Spring lock washers for screw assemblies. |
| Italy | UNI | UNI 1751 | Spring washers (Rondelle elastiche). |
| Poland | PN | PN M-82008 | Spring lock washers. |
We are a Leading Stockiest and Dealer supplying Spring Washers in the following grades:
| Grade | UNS | W.Nr. |
|---|---|---|
| Spring Washer SS 304 | S30400 Spring Washers DIN 127B | 1.4301 Spring Washers DIN 127B |
| Spring Washer SS 304L | S30403 Spring Washers DIN 127B | 1.4306 Spring Washers DIN 127B |
| Spring Washer SS 316 | S31600 Spring Washers DIN 127B | 1.4401 Spring Washers DIN 127B |
| Spring Washer SS 316L | S31603 Spring Washers DIN 127B | 1.4404 Spring Washers DIN 127B |
| Spring Washer SS 316Ti | S31635 Spring Washers DIN 127B | 1.4571 Spring Washers DIN 127B |
| Spring Washer SS 310S | S31008 Spring Washers DIN 127B | 1.4845 Spring Washers DIN 127B |
| Spring Washer 17-4 PH | S17400 Spring Washers DIN 127B | 1.4542 Spring Washers DIN 127B |
| Grade | UNS | Description |
|---|---|---|
| Spring Washer Monel 400 | N04400 Spring Washers DIN 127B | For marine applications. |
| Spring Washer Inconel 625 | N06625 Spring Washers DIN 127B | For high temp & corrosion. |
| Spring Washer Inconel 718 | N07718 Spring Washers DIN 127B | High strength aerospace grade. |
| Spring Washer Hastelloy C276 | N10276 Spring Washers DIN 127B | Chemical processing. |
| Spring Washer Titanium Gr 2 | R50400 Spring Washers DIN 127B | Lightweight & bio-compatible. |
Dipti Metal Industries is the Largest Exporter and Biggest Supplier of Spring Washers DIN 127B. We supply to Distributors and Stockiest networks in the following regions:
Contact the Biggest Supplier of Spring Washers DIN 127B today.
