Leading API 6A Type 6BX 3000 PSI Flange Manufacturer, API 6A Type 6BX 3000 PSI Flanges Supplier & API 6A Type 6BX 3000 PSI Flanges Exporter (3000 PSI / 20.7 MPa) in Mumbai, India
Dipti Metal Industries is a Leading global API 6A Type 6BX Flange Manufacturer, API 6A Type 6BX 3000 PSI Flange Supplier & API 6A Type 6BX 3000 PSI Flange Exporter of 20.7 MPa (3000 PSI) flanged products for high-integrity, severe service in Mumbai, India. The Type 6BX flange uses BX Ring Type Joint (RTJ) Gaskets and is a **bolt-preloaded** connection, designed for superior resistance to external bending moments and pressure compared to the Type 6B. We focus on providing certified 6BX Flanges, particularly in large nominal sizes (e.g., 26 3/4" and 30") for wellhead and blowout preventer (BOP) applications. We ensure supply meets all material classes (DD, EE, FF) and Product Specification Levels (PSL 1-4), adhering strictly to NACE MR0175/ISO 15156 for sour service. Find certified API 6A 6BX Flanges here.
🏭 About Dipti Metal Industries — Your API 6A Partner
Founded in 2009 in Mumbai, India, we are a specialized global API 6A Flange Manufacturer and API 6A Type 6BX 3000 PSI Flange Exporter focused on high-integrity components for the energy sector. Our manufacturing and inspection processes are tailored to meet the exacting requirements of API 6A PSL levels, ensuring our Type 6BX 3000 PSI flanges deliver maximum performance in medium-to-high pressure applications. We stock and supply both common and large nominal sizes (e.g., 26 3/4" and 30"), complete with material traceability and compliance for upstream oilfield projects globally.
Certifications & Compliance
- ISO 9001 Quality Management System
- EN 10204 3.1 / 3.2 Material Test Certificates
- Compliance with API 6A (latest edition)
- Sour Service Compliance: NACE MR-0175 / ISO 15156
Why Dipti for API 6BX Flanges
- Stock focus on large bore sizes (26 3/4" and 30") in Mumbai for immediate project needs
- Flanges certified to PSL 3 & PSL 4 when required for critical wellhead duties
- Expertise in the critical dimensions required for **BX Ring Gaskets** for reliable preloaded seals
- Complete documentation and global logistics (FOB/CFR/CIF/EXW/FCA)
📘 Product Overview: API 6A Type 6BX (3000 PSI / 20.7 MPa)
The API 6A Type 6BX connection is highly regarded for its greater strength and stability under bending and thermal loads compared to Type 6B. It operates as a **bolt-preloaded** system, using the high tensile strength of the bolting to maintain a superior metal-to-metal seal via the **Type BX Ring Gasket**. At 3000 PSI (20.7 MPa), the 6BX design provides a critical, high-integrity flange face essential for components exposed to significant operational stresses in mid-pressure drilling and production environments.
API 6A & ISO 10423 Standard Specifications
| Parameter | Specification |
|---|---|
| Design Standard | API Spec 6A (and ISO 10423) |
| Flange Type | Type 6BX |
| Max Working Pressure | 3000 PSI (20.7 MPa) |
| Sealing Face | Ring Type Joint (RTJ) - Uses BX Series Gaskets |
| Key Feature | Bolt Preloaded - High resistance to external bending loads |
| Product Spec. Levels | PSL 1, PSL 2, PSL 3, PSL 4 |
We supply flanges in material classes DD, EE, FF and temperature ratings from L, P, R, S, T, U, V, X, and Y as per API 6A.
Common Forged Material Grades Supplied
| Application | ASTM / ASME Grade |
|---|---|
| Carbon Steel | ASTM A105 / A105N, A350 LF2 |
| Low Alloy Steel | ASTM A182 F5, F11, F22 |
| Stainless Steel | ASTM A182 F304, F316 |
| Duplex & Super Duplex | ASTM A182 F51, F53, F55 |
All materials can be supplied with NACE MR0175 / ISO 15156 compliance for sour service.
API 6A Type 6BX 3000 PSI Ring Joint Gasket Groove Dimensions (BX RTJ)
The table below provides the essential dimensions for the BX Ring Joint Gasket Groove for API 6A Type 6BX 3000 PSI flanges, specified in mm. This data is critical for proper sealing with BX series ring gaskets in large nominal sizes.
| Size | OD | C | E1 | G | K | T | J1 | J4 | R | BC | N | H | Ring Number BX |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 26 3/4" | 1100 | 6 | 21.4 | 774.22 | 832 | 161.2 | 870 | 0 | 16 | 1000.10 | 24 | 54 | 168 |
| 30" | 1185 | 6 | 23 | 862.30 | 922 | 167.1 | 970 | 12.7 | 16 | 1090.60 | 32 | 51 | 303 |
UNIT: mm. Dimensions are for the Ring Groove based on API 6A Table 5.10.
NOTE 1) TOLERANCE ACCORDING TO API 6A - 20TH
NOTE 2) RING GASKET ACCORDING TO API 6A-20TH
API 6A Type 6BX 3000 PSI Flange & Connection Product Range
We supply the full range of components designed and manufactured strictly to API 6A, 3000 PSI Type 6BX standards for high-integrity connections, particularly in large nominal sizes.
- API 6A Type 6BX Weld Neck Flanges (Available in 26 3/4" and 30" bore sizes) (Weld Neck Flange Category)
- API 6A Type 6BX Blind Flanges (For sealing ends of wellhead equipment) (Blind Flange Category)
- API BX Series Ring Gaskets (BX168, BX303) - Mandatory for 6BX connection
- High-Tensile Bolting (ASTM A193 B7 / A320 L7 with A194 Nuts) (B7 Bolting Page)
- Flange Adapters and Transition Spools (6BX to 6B or other standards)
Key Applications for API 6A Type 6BX 3000 PSI Flanges
The 6BX design at 3000 PSI is a workhorse for robust, permanent, and high-integrity sealing in the following environments:
- Wellhead Assemblies: Used as primary connectors for casing and tubing head spools requiring enhanced load resistance.
- Christmas Trees: Connecting valves, chokes, and crosses, especially where external stresses or bending moments are present.
- Large-Diameter Piping: Interconnecting large-bore production and injection lines in critical facilities.
- BOP (Blowout Preventer) Stacks: Connections for BOP equipment rated for this pressure class and requiring preloaded sealing integrity.
Global Distribution Network for API 6A Flanges
As a global API 6A Flange Exporter and Supplier, Dipti Metal Industries specializes in the delivery of certified, high-pressure components for the most demanding oil and gas and energy projects worldwide.
Major Markets Served by Our API 6A Flange Exporter Network
- Austria: Vienna, Salzburg
- Belgium: Antwerp, Brussels, Ghent
- Bulgaria: Sofia, Plovdiv
- Croatia: Zagreb, Split
- Czech Republic: Prague, Brno
- Denmark: Copenhagen, Aarhus
- Estonia: Tallinn, Tartu
- Finland: Helsinki, Tampere
- France: Paris, Marseille, Lyon
- Germany: Frankfurt, Hamburg, Munich, Düsseldorf
- Greece: Athens, Thessaloniki
- Hungary: Budapest, Debrecen
- Ireland: Dublin, Cork
- Italy: Milan, Rome, Genoa
- Latvia: Riga, Daugavpils
- Lithuania: Vilnius, Kaunas
- Luxembourg: Luxembourg City
- Netherlands: Rotterdam, Amsterdam, The Hague
- Norway: Oslo, Bergen
- Poland: Warsaw, Krakow
- Portugal: Lisbon, Porto
- Romania: Bucharest, Cluj-Napoca
- Russia: Moscow, Saint Petersburg, Kazan
- Serbia: Belgrade, Novi Sad
- Slovakia: Bratislava, Košice
- Slovenia: Ljubljana, Maribor
- Spain: Madrid, Barcelona, Valencia
- Sweden: Stockholm, Gothenburg
- Switzerland: Zurich, Geneva, Basel
- Ukraine: Kyiv, Kharkiv, Odesa
- United Kingdom: London, Manchester, Aberdeen, Glasgow
- Afghanistan: Kabul, Kandahar
- Bahrain: Manama, Sitra
- Bangladesh: Dhaka, Chittagong
- Brunei: Bandar Seri Begawan
- China: Shanghai, Guangzhou, Tianjin, Shenzhen
- Hong Kong: Hong Kong City
- India: Mumbai, Delhi, Chennai, Kolkata, Bangalore, Hyderabad (Local Markets)
- Indonesia: Jakarta, Surabaya, Balikpapan
- Iran: Tehran, Mashhad
- Iraq: Baghdad, Basra
- Japan: Tokyo, Osaka, Nagoya
- Jordan: Amman, Irbid
- Kazakhstan: Nur-Sultan, Almaty
- Kuwait: Kuwait City, Ahmadi
- Laos: Vientiane, Luang Prabang
- Lebanon: Beirut, Tripoli
- Malaysia: Kuala Lumpur, Johor Bahru, Port Klang
- Myanmar: Yangon, Mandalay
- Nepal: Kathmandu, Biratnagar
- Oman: Muscat, Sohar, Salalah
- Philippines: Manila, Cebu
- Qatar: Doha, Ras Laffan
- Saudi Arabia: Riyadh, Jeddah, Dammam, Al Khobar, Jubail
- Singapore: Singapore City
- South Korea: Seoul, Busan, Ulsan
- Sri Lanka: Colombo, Kandy
- Syria: Damascus, Aleppo
- Taiwan: Taipei, Kaohsiung
- Thailand: Bangkok, Rayong, Laem Chabang
- UAE: Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah
- Uzbekistan: Tashkent, Samarkand
- Vietnam: Ho Chi Minh City, Hanoi, Da Nang
- Yemen: Sana'a, Aden
- Canada: Calgary, Edmonton, Vancouver, Toronto, Montreal
- Mexico: Mexico City, Monterrey, Guadalajara
- Panama: Panama City, Colón
- USA: Houston, Los Angeles, New York, Chicago, New Orleans
- Argentina: Buenos Aires, Cordoba
- Bolivia: La Paz, Santa Cruz
- Brazil: São Paulo, Rio de Janeiro, Salvador
- Chile: Santiago, Valparaíso
- Colombia: Bogota, Medellin
- Ecuador: Quito, Guayaquil
- Peru: Lima, Arequipa
- Uruguay: Montevideo
- Venezuela: Caracas, Maracaibo
- Algeria: Algiers, Oran
- Angola: Luanda, Huambo
- Egypt: Cairo, Alexandria, Port Said
- Ghana: Accra, Kumasi
- Kenya: Nairobi, Mombasa
- Libya: Tripoli, Benghazi
- Morocco: Casablanca, Rabat
- Mozambique: Maputo, Beira
- Nigeria: Lagos, Port Harcourt, Abuja
- Rwanda: Kigali, Rubavu
- South Africa: Johannesburg, Durban, Cape Town, Sasolburg
- Tanzania: Dar es Salaam, Mwanza
- Tunisia: Tunis, Sfax
- Uganda: Kampala, Gulu
- Australia: Sydney, Melbourne, Perth, Brisbane
- Fiji: Suva, Nadi
- New Zealand: Auckland, Wellington, Christchurch
- Papua New Guinea: Port Moresby, Lae
Why Procure Your API 6A Type 6BX Flanges from Dipti Metal Industries?
- API Certification Assurance: We guarantee compliance with the latest API 6A specifications for design, manufacture, and pressure rating (20.7 MPa / 3000 PSI).
- Type 6BX Expertise: Deep understanding of the bolt-preloaded 6BX design criteria, ensuring superior resistance to external loads compared to 6B flanges.
- Large Bore Specialization: Proven capability to supply large-diameter (26 3/4", 30") flanges and critical connections for main casing and wellhead equipment.
- Full BX Gasket System: Guaranteed supply of precision-machined BX Series Ring Gaskets (BX168, BX303) for flawless, high-integrity seal performance.
Request a Custom Quote for API 6A Type 6BX Flanges (3000 PSI)
Contact Dipti Metal Industries today for certified API 6A Type 6BX 3000 PSI Flanges, Flanged Fittings, and matching BX Ring Gaskets. Provide your project specifications including required PSL, Material Class, BX Ring Gasket Number, and nominal size (e.g., 26 3/4" or 30") for a competitive, customized quote and expert technical support.
