Outlet
Size

A' Dimensions (Height above run pipe)

1 1/2

2

2 1/2

3

4

5

6

8

10

12

14

16

18

20

24

Std Wt Run Pipe

1.50

1.50

1.62

1.75

2.00

2.25

2.38

2.75

3.06

3.38

3.50

3.75

3.81

4

4.56

XS Run Pipe

1.50

1.50

1.62

1.75

2.00

2.25

3.06

3.87

3.69

4.06

3.81

4.19

4.38

4.69

5.50

.500" to .750" Thick Run Pipe

-

-

-

2.88

3.31

3.75

4.12

4.18

4.25

4.37

4.50

4.69

5.13

5.62

6.50

.750" to 1.00" Thick Run Pipe

-

-

-

3.22

3.38

3.75

4.34

4.62

4.84

5.10

5.25

5.88

6.50

6.75

7.62

1.00" to 1.25" Thick Run Pipe

-

-

-

3.38

3.50

4.00

4.50

4.88

5.00

5.38

5.50

6.00

6.50

7.00

8.00

1.25" to 1.50" Thick Run Pipe

-

-

-

3.62

3.87

4.25

4.69

5.16

5.31

5.68

5.81

6.44

6.50

7.56

8.72

Outlet
Size

*'W' Dimensions (Max. O.D. of fitting - Max. size of hole)

1 1/2

2

2 1/2

3

4

5

6

8

10

12

14

16

18

20

24

Std Wt Run Pipe

3.50

4.25

4.88

5.69

7.00

8.06

9.71

11.71

14.00

16.32

17.56

19.75

22.00

24.00

29.00

XS Run Pipe

3.56

4.38

5.00

5.75

7.12

8.25

10.44

13.44

14.25

16.56

18.00

20.00

22.44

25.00

30.32
