DIPTIINOX® ER316LSi TIG Rod (AWS A5.9): Leading High-Silicon Low-Carbon Manufacturer & Exporter for Premium Weldability
Dipti Metal Industries is a Leading ER316LSi TIG Rod Manufacturer and High-Silicon Low-Carbon Welding Wire ER316LSi TIG Rod Exporter in Mumbai, India, specializing in high-performance AWS A5.9 ER316LSi GTAW filler metal under the DIPTIINOX® brand. This wire is the enhanced version of ER316L, retaining its low carbon content (0.03% max) for complete protection against intergranular corrosion (weld decay), but with a significantly increased Silicon (Si) level (0.65% - 1.00%). The added silicon dramatically improves weld pool fluidity, enhances arc stability, and results in a smooth, clean bead profile, thereby minimizing post-weld grinding. It affords the same high resistance to pitting corrosion as ER316L due to the Molybdenum. It is the preferred choice for both TIG and high-speed automated MIG applications demanding the best possible weld appearance and operability. We guarantee full conformance to AWS A5.9 for critical industrial applications globally.
DIPTIINOX® ER316LSi: Low-Carbon Corrosion Resistance with Enhanced Weldability
The AWS A5.9 ER316LSi Filler Metal offers the same core chemical characteristics and corrosion performance as ER316L—specifically the low carbon (0.03% max) for intergranular corrosion resistance and 2.0% - 3.0% Molybdenum for pitting resistance. The key differentiator is the significantly higher silicon content (0.65% - 1.00%). While silicon is typically a trace element, its elevation in the ER316LSi grade provides tangible benefits to the welding process, particularly improving the fluidity and 'wet-out' of the molten weld pool. This makes it an outstanding choice for automated processes like MIG (GMAW), where it dramatically improves wire feeding, arc stability, and bead shape. For TIG (GTAW), it results in a cleaner, smoother weld surface with minimal need for post-weld conditioning, affording the same strong assurance against intergranular corrosion as ER316L. It is available as TIG Rod (GTAW), and is highly recommended as MIG Wire (GMAW).
Key Features, Benefits, and Conformances of ER316LSi Filler Metal
Key Features & Service Performance (As per Datasheet)
- High Silicon (Si): Controlled to 0.65% - 1.00% for optimal arc stability and bead profile.
- Enhanced Fluidity: Superior weld pool fluidity ('wet-out') drastically reduces post-weld grinding.
- Low-Carbon Content: Carbon restricted to 0.03% max for weld decay resistance (intergranular corrosion).
- Molybdenum Pitting Resistance: Maintains 2.0% - 3.0% Mo for resistance to chlorides and acids.
- Weldability: Significantly improved wire feeding characteristics for automated welding systems.
International Conformances and Quality
- Form: Solid Wire/Rod for TIG (GTAW), and spools for MIG (GMAW).
- Finish: Bright finish for TIG, layer-wound spools for consistent feed.
AWS A5.9 ER316LSi - Chemical Composition and Mechanical Properties
AWS Chemical Composition Requirements (%)
| C max | Cr | Ni | Mo | Mn | Si | P max | S max | Cu max |
|---|---|---|---|---|---|---|---|---|
| 0.03 | 18.0 – 20.0 | 11.0 – 14.0 | 2.0 – 3.0 | 1.0 – 2.5 | 0.65 – 1.00 | 0.03 | 0.03 | 0.75 |
Deposited Chemical Composition % (Typical)
| C | Cr | Ni | Mo | Mn | Si | P | S |
|---|---|---|---|---|---|---|---|
| 0.02 | 18.50 | 11.50 | 2.50 | 1.70 | 0.90 | 0.010 | 0.013 |
Mechanical Properties (R.T.) of Deposited All Weld Metal (Typical)
| Yield Strength (psi) | Tensile Strength (psi) | Elongation % | Reduction of Area % |
|---|---|---|---|
| 58,000 | 88,000 | 37% | 68% |
Data is typical for ER316LSi weld metal deposited by TIG (GTAW) using 100% Argon as the shielding gas.
Welding Parameters, Diameter Range, and Packaging Options
Our ER316LSi Filler Metal is highly sought after in cut lengths for TIG (GTAW) and especially in spools for automated MIG (GMAW) processes due to its superior operability. The high silicon assists greatly with bead tie-in and surface finish.
Recommended Welding Parameters (GTAW - TIG Process) - DCSP
| Wire Diameter (in) | Amps (DCSP) | Volts | Shielding Gas | Note |
|---|---|---|---|---|
| .035 | 60-90 | 12-15 | Argon 100% | Parameters are dependent upon plate thickness and welding position. Preheat is generally not required; max interpass temperature is typically 150°C / 300°F. |
| .045 | 80-110 | 13-16 | ||
| 1/16 | 90-130 | 14-16 | ||
| 3/32 | 120-175 | 15-20 |
Note: For MIG (GMAW) welding, the high silicon content significantly improves droplet transfer and weld pool shape, making it the superior choice for thin gauges and automatic welding.
Standard Diameters & Packaging (GTAW - TIG Rods)
| Diameter (in) | Diameter (mm) | Length (in) | Length (mm) | Packaging (kgs) |
|---|---|---|---|---|
| .030 | 0.8 | 36 | 914 | 5 kgs (Plastic Container) |
| .035 | 0.9 | 36 | 914 | 5 kgs (Plastic Container) |
| .045 | 1.2 | 36 | 914 | 5 kgs (Plastic Container) |
| 1/16 | 1.6 | 36 | 914 | 5 kgs (Plastic Container) |
| 3/32 | 2.4 | 36 | 914 | 5 kgs (Plastic Container) |
| 1/8 | 3.2 | 36 | 914 | 5 kgs (Plastic Container) |
| 5/32 | 4.0 | 36 | 914 | 5 kgs (Plastic Container) |
| 3/16 | 4.8 | 36 | 914 | 5 kgs (Plastic Container) |
We also supply ER316LSi in spools (2#, 10#, 25#, 30#, 33#) for MIG/GMAW and coils for SAW on request.
Primary Applications for DIPTIINOX® ER316LSi TIG Rod & Wire
The ER316LSi filler metal is specified when the highest levels of weld integrity and cosmetic finish are required alongside the corrosion resistance of 316L, especially in automated welding environments. Its key uses include:
- Automated Welding (MIG/GMAW): Ideal for robotic welding and high-speed production lines due to its superior arc stability and wire feed characteristics.
- Pipe & Tube Fabrication: Welding Type 316L piping where smooth internal and external bead profiles are critical for fluid flow and inspection.
- Corrosion-Critical Vessels: Process vessels and tanks in the chemical, pharmaceutical, and food industries where surface finish affects cleanliness and crevice corrosion risk.
- As-Welded Service: All applications requiring low-carbon content for intergranular corrosion resistance in the post-weld condition.
- Joints Exposed to Chlorides: Components in marine, pulp and paper, and textile finishing equipment where pitting corrosion is a risk.
ER316LSi TIG Rods Global Export Markets: We are the Biggest ER316LSi TIG Rod Manufacturer Supplying from Mumbai, India
Dipti Metal Industries is a proud ER316LSi TIG Rod Exporter, ER316LSi TIG Rod Trader, and ER316LSi TIG Rod Distributors from our base in TIG rod ER316LSi TIG Rod manufacturer Mumbai, India. We serve as an ER316LSi manufacturer in Asia and a reliable ER316LSi manufacturer in Europe, ensuring timely and compliant delivery to major industrial hubs across over 190 countries globally.
Explore Our Extensive Global Reach (Illustrative Markets)
- USA: Houston, Los Angeles, New York, Chicago, New Orleans
- Canada: Calgary, Edmonton, Vancouver, Toronto, Montreal
- Mexico: Mexico City, Monterrey, Guadalajara, Veracruz
- Panama: Panama City, Colón
- Trinidad and Tobago: Port of Spain, San Fernando
- Costa Rica: San José, Puerto Limón
- Guatemala: Guatemala City, Puerto Quetzal
- Honduras: Tegucigalpa, San Pedro Sula
- Nicaragua: Managua, Corinto
- El Salvador: San Salvador, Acajutla
- Jamaica: Kingston, Montego Bay
- Dominican Republic: Santo Domingo, Santiago
- Cuba: Havana, Santiago de Cuba
- Bahamas: Nassau, Freeport
- Barbados: Bridgetown
- Haiti: Port-au-Prince
- Puerto Rico: San Juan
- Belize: Belize City
- Brazil: São Paulo, Rio de Janeiro, Salvador, Curitiba
- Argentina: Buenos Aires, Cordoba, Rosario
- Chile: Santiago, Valparaíso, Concepción, Antofagasta
- Colombia: Bogotá, Medellín, Cartagena, Barranquilla
- Peru: Lima, Callao, Arequipa, Trujillo
- Venezuela: Caracas, Maracaibo, Puerto La Cruz, Valencia
- Ecuador: Quito, Guayaquil, Manta, Esmeraldas
- Bolivia: La Paz, Santa Cruz, Cochabamba
- Uruguay: Montevideo, Salto
- Paraguay: Asunción, Ciudad del Este
- Guyana: Georgetown
- Suriname: Paramaribo
- Germany: Frankfurt, Hamburg, Munich, Düsseldorf, Berlin
- United Kingdom: London, Manchester, Aberdeen, Glasgow, Liverpool
- Netherlands: Rotterdam, Amsterdam, The Hague
- France: Paris, Marseille, Lyon, Le Havre, Bordeaux
- Italy: Milan, Rome, Genoa, Venice, Naples
- Spain: Madrid, Barcelona, Valencia, Bilbao, Seville
- Russia: Moscow, Saint Petersburg, Kazan, Novorossiysk, Sochi
- Poland: Warsaw, Krakow, Gdańsk, Wrocław
- Belgium: Antwerp, Brussels, Ghent, Zeebrugge
- Sweden: Stockholm, Gothenburg, Malmö, Uppsala
- Norway: Oslo, Bergen, Stavanger, Trondheim
- Finland: Helsinki, Tampere, Turku, Oulu
- Turkey: Istanbul, Ankara, Izmir, Adana
- Portugal: Lisbon, Porto, Sines
- Greece: Athens, Thessaloniki, Patras
- Ireland: Dublin, Cork
- Austria: Vienna, Salzburg, Linz
- Switzerland: Zurich, Geneva, Basel, Bern
- Czech Republic: Prague, Brno, Ostrava
- Romania: Bucharest, Cluj-Napoca, Constanța
- Ukraine: Kyiv, Kharkiv, Odesa, Lviv
- Hungary: Budapest, Debrecen, Szeged
- Croatia: Zagreb, Split, Rijeka
- Denmark: Copenhagen, Aarhus, Odense
- Slovakia: Bratislava, Košice, Žilina
- Lithuania: Vilnius, Kaunas, Klaipėda
- Latvia: Riga, Daugavpils, Liepāja
- Estonia: Tallinn, Tartu, Narva
- Bulgaria: Sofia, Plovdiv, Varna
- Serbia: Belgrade, Novi Sad
- Slovenia: Ljubljana, Maribor
- Cyprus: Nicosia, Limassol
- Malta: Valletta, Birkirkara
- Saudi Arabia: Riyadh, Jeddah, Dammam, Al Khobar, Jubail
- UAE: Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah
- Qatar: Doha, Ras Laffan
- Oman: Muscat, Sohar, Salalah
- Kuwait: Kuwait City, Ahmadi
- Bahrain: Manama, Sitra
- Iraq: Baghdad, Basra, Erbil
- Iran: Tehran, Mashhad, Bandar Abbas, Isfahan
- India: Mumbai, Delhi, Chennai, Kolkata, Bangalore, Hyderabad (Local Markets)
- China: Shanghai, Guangzhou, Tianjin, Shenzhen, Qingdao, Hong Kong
- Japan: Tokyo, Osaka, Nagoya, Yokohama, Kobe
- South Korea: Seoul, Busan, Ulsan, Incheon, Daegu
- Indonesia: Jakarta, Surabaya, Balikpapan, Medan
- Singapore: Singapore City
- Malaysia: Kuala Lumpur, Johor Bahru, Port Klang, Penang
- Thailand: Bangkok, Rayong, Laem Chabang, Chiang Mai
- Vietnam: Ho Chi Minh City, Hanoi, Da Nang, Haiphong
- Philippines: Manila, Cebu, Davao, Batangas
- Bangladesh: Dhaka, Chittagong, Khulna
- Pakistan: Karachi, Lahore, Islamabad, Faisalabad
- Taiwan: Taipei, Kaohsiung, Taichung
- Myanmar: Yangon, Mandalay
- Sri Lanka: Colombo, Kandy
- Kazakhstan: Nur-Sultan, Almaty, Atyrau
- Uzbekistan: Tashkent, Samarkand, Bukhara
- Jordan: Amman, Irbid, Zarqa
- Lebanon: Beirut, Tripoli
- Mongolia: Ulaanbaatar, Erdenet
- Nepal: Kathmandu, Biratnagar
- Yemen: Sana'a, Aden
- South Africa: Johannesburg, Durban, Cape Town, Sasolburg
- Nigeria: Lagos, Port Harcourt, Abuja, Kano
- Egypt: Cairo, Alexandria, Port Said, Suez
- Algeria: Algiers, Oran, Skikda
- Morocco: Casablanca, Rabat, Tangier
- Angola: Luanda, Lobito
- Kenya: Nairobi, Mombasa
- Tanzania: Dar es Salaam, Mwanza
- Ghana: Accra, Tema, Kumasi
- Mozambique: Maputo, Beira
- Cameroon: Douala, Yaoundé
- Libya: Tripoli, Benghazi
- Tunisia: Tunis, Sfax
- Ethiopia: Addis Ababa, Dire Dawa
- Australia: Sydney, Melbourne, Perth, Brisbane, Darwin, Adelaide
- New Zealand: Auckland, Wellington, Christchurch
- Papua New Guinea: Port Moresby, Lae
- Fiji: Suva, Nadi
- Zambia: Lusaka, Ndola
- Zimbabwe: Harare, Bulawayo
- Namibia: Windhoek, Walvis Bay
- Democratic Republic of Congo: Kinshasa, Lubumbashi
- Cote d'Ivoire: Abidjan
- Senegal: Dakar
- Mali: Bamako
- Malawi: Lilongwe, Blantyre
- Mauritius: Port Louis
- Reunion: Saint-Denis
Get a Quote Today for Your ER316LSi Filler Metal Requirements!
Are you searching to buy ER316LSi TIG Rod or ER316LSi MIG Wire that is dependable, high-quality, and AWS A5.9 certified for your automated or critical low-carbon Molybdenum applications? Contact Dipti Metal Industries, your expert biggest manufacturer and ER316LSi TIG Rod Manufacturer, High-Silicon GTAW/GMAW Filler Metal Supplier in Mumbai, India, today to discuss your specific requirements or to request a personalized, custom quote. Our team is dedicated to providing you with the most effective, safest, and most reliable DIPTIINOX® ER316LSi solutions.
Price guidance (non-binding): USD 10.50–66.00 per kg depending on grade, diameter, packaging (Rod/Spool/Coil), quantity, and delivery terms. Final prices are quotation-based.
ER316LSi TIG Rod & Wire — Frequently Asked Questions
The 'Si' denotes a higher Silicon content (0.65% - 1.00%) compared to standard ER316L. Silicon is added primarily to increase the weld pool fluidity and improve the wetting action of the weld metal. This results in superior bead shape, cleaner weld surfaces, better arc stability, and less grinding, which is especially beneficial for automated welding processes (MIG/GMAW).
The primary corrosion resistance, including pitting resistance, is maintained by the Molybdenum and low carbon content (0.03% max), similar to ER316L. While high silicon can slightly affect the microstructure, the ER316LSi composition is balanced to retain excellent intergranular and pitting corrosion performance, matching the demands of 316L base metal.
ER316LSi is generally an upgrade for ER316L, particularly where weldability, bead appearance, and wire feeding (MIG) are critical. In TIG (GTAW), the added silicon improves the cleanliness and fluidity of the puddle. It provides all the corrosion benefits of 316L and is often chosen as the go-to low-carbon molybdenum filler metal.
Yes, ER316LSi is commonly manufactured in large coil form for SAW. The selection of the correct welding flux is critical for SAW, as the flux's chemistry significantly influences the final weld metal's silicon and carbon content, impacting the weld's mechanical and corrosion properties.
